Residential swing gate opener, moves gates up to 200kg and 2.5 meters wide(each single swing).
Optional installation accessories available in two styles.
Available in AC mains power 110V/220V and DC 24V. Compact, aesthetic design, screw-driven action.
Planetary gear motor with planetary transmission, ensures low-noise operation.
Wi-Fi support, with an app, every motion is under control.
Security and safety, supports various of safety sensors, flashing lights. Safety reversing after detecting obstructions.
Featured with soft start-slow close function and automatic close function.
Backup battery support, allows for completing certain operations even when there is no mains power.
paramenters
| Model number | SW200DC | SD200DC |
| Power Supply | AC110V/60Hz; AC220V/50Hz | |
| Maximum Loading Gate Weight | 200KG/single swing | |
| Maximum Loading Gate Length | 2.5m | |
| Maximum Stroke of Lead Screw | 32cm | |
| Motor Power | DC24V/30W | |
| Transmission Mode | Lead Screw | |
| Limit Switch | Block Stop | |
| Moving Speed | 22s/90° | |
| Remote Control Range | ≥30m | |
| Recording of up Remote Controls | 32 | |
| Remote Control Frequency | 433.92MHz | |
| Work Duty | S2 30min | |
| Noise | ≤58dB | |
| Working Temperature | -20°C ~ +70°C | |
| Package Weight | 14.5KG | |
